• 6 years or 500,000 km service life (whichever comes first)
• Guaranteed to suit every vehicle
• Provides optimum protection against corrosion of all metals in vehicle cooling systems
• Compatible with hoses and rubber fittings
• Expands operating temperature range of cooling systems
• Eliminates the need for supplemental coolant additives (SCA) in diesel engines
• Reduces the incidence of nucleate or hot spot boiling
• Not aggressive to water pump seals as is often the case with high silicate content coolants
• Performance of organic additive based inhibitors does not diminish with time
• Reduces inventory for fleet operators

Nulon LLTU is recommended for the protection of cooling systems of all petrol engines and heavy and ligh-duty diesel engines operating in on-road, off-road or stationary conditions. LLTU provides maximum protection against cavitation erosion of wet cylinder liners in diesel engines. Refer to Nulon Fact Sheet No.108 for more information re diesel engine applications. (Note: for maximum protection, particularly in heavy-duty diesel applications, use Long Life Concentrated Coolant (LL) at 50% volume with clean soft or demineralised water).

LLTU is guaranteed to be suitable for the protection of cooling systems of all passenger vehicles where an anti-freeze/anti-boil coolant is specified. Nulon LLTU is also suitable for older vehicles where a broader cooling system operating temperature range is desired, or as a replacement for conventional corrosion inhibitors.

Note: Where a manufacturer specifies Organic Additive Technology (OAT) long life coolant, use either of Nulon's Red Long Life Coolants.

Recommended step-by-step guide for changing coolants

1. Before proceeding, read your owner's manual as some vehicles may have special requirements.
2. Check that all hose connections are tight. Also check the condition of all hoses, fittings and belts.
3. Use Nulon Radiator Flush and Clean (R40) to ensure that the radiator and engine are as clean as possible. This ensures maximum coolant life.
4. R40 should be added to the old coolant. With the heater on, run the engine, or drive for 20 minutes minimum, 1 hour maximum.
5. Stop the engine and allow it to cool. Remove the bottom radiator hose or drain plug to drain out all the old coolant. It is important to rinse out all traces of old coolant from the engine block and heater circuit. To best achieve this refill the system with clean water - run the engine up to operating temperature and when it is cool drain and flush again. This will ensure a clean environment for the new coolant.
6. Check the cooling system capacity of the vehicle and add the required dose of Nulon Concentrated Coolant (do not pre-mix), then fill with soft clean or demineralised water. Any leftover product can be pre-diluted and used as a top-up.
7. Some vehicles may require "air bleeding" to remove trapped air from the heater circuit and cylinder head. An air bleeding screw is located on the engine of some vehicles for this purpose. If you are unsure about this procedure please seek further advice before proceeding. Removing the return heater hose from the water pump to establish water flow, whilst topping up, will assist in reducing "air locks". Note: air locks can cause severe engine damage.
8. Start the engine and monitor coolant level and temperature until the thermostat opens and the vehicle reaches operating temperature.
9. When the vehicle cools down re-check the coolant level.

Note: This check sheet should be used as a guide only. Some vehicles may have special requirements that are not noted above. We strongly advise that you read your owner's manual or relevant workshop manual before proceeding with a coolant change.

Temperature protection chart (using105 kPa radiator cap)

Simulated Service Test (ASTM D 2570)

Glassware Corrosion Test (ASTM D 1384) S

* wt. loss mg (max)

Water Pump Cavitation Erosion Test (ASTM D 2809)

Aluminium Heat Rejection Corrosion Test (ASTM D 4340)

SAFETY: Harmful if swallowed. May cause respiratory irritation. Use only outdoors or in a well-ventilated area. Store locked up.

FIRST AID: IF SWALLOWED: Immediately call a POISON CENTRE or doctor/physician. Rinse mouth. IF INHALED: Remove victim to fresh air and keep at rest in a position comfortable for breathing. For advice, contact a Poisons Information Centre (e.g. phone Australia 13 11 26; New Zealand 0800 764 766) or a doctor (at once).

ENVIRONMENT: Do not pollute drains, soil or water with used products. After use, dispose of container in a responsible manner. Disposal of container
should comply with local council regulations.
